液体火箭发动机故障尾焰光谱诊断：从定性到定量

doi:10.7527/S1000-6893.2026.33069

Abstract

Abstract:

With the growing engineering demand for reusable liquid rocket engines， ensuring stable and safe operation under extreme conditions-high heat flux， high chamber pressure， and violent combustion-has become increasingly challenging. Plume spectroscopic diagnostics， featuring non-contact measurement， high sensitivity， and multi-parameter sensing capability， has emerged as an important technical route for engine health monitoring and fault identification. We first analyze the key challenges in liquid rocket engine development and the diagnostic requirements for fault monitoring. The diagnostic mechanism based on atomic emission spectroscopy is then systematically elaborated， followed by a review of domestic and international research progress and the current state of the art in plume spectroscopy. Next， the core enabling technologies are summarized， including the construction of a spectrum–material–fault-mode database， controlled metal-impurity doping combustion tests， quantitative inversion of alloy species concentrations in the plume， flight-environment spectral diagnostics， and spectral-line interference and mitigation strategies for LOX/kerosene engines. The applicability， accuracy， and engineering feasibility of three representative measurement techniques-Fabry-Pérot interferometry， Fourier-transform infrared spectroscopy， and laser-induced breakdown spectroscopy-are further evaluated and compared for plume spectral acquisition. Finally， future trends are discussed， with emphasis on multimodal data fusion， artificial-intelligence-enabled analysis， on-chip spectroscopy combined with edge computing， and extensions toward the near-/mid-/far-infrared and terahertz bands， highlighting the broad prospects of plume spectroscopy for intelligent operation and predictive maintenance of liquid rocket engines.

Key words: liquid rocket engine, exhaust plume spectroscopy, fault diagnosis, quantitative inversion, artificial intelligence

CLC Number:

V434

Song YAN, Yi LI, Hongqiang QIN, Xing CUI, Yushan GAO. Exhaust-plume spectroscopic diagnostics of liquid rocket engine faults: From qualitative to quantitative[J]. Acta Aeronautica et Astronautica Sinica, 2026, 47(16): 133069.

Figures/Tables 17

Fig.1

Fig.2

Table 1

Table 2

Table 3

Table 4

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

Fig.10

Fig.11

Fig. 12

Table 5

References 94

[1]	杨述明，吴建军，谢昌霖，等. 数据驱动智能故障诊断技术在液体火箭发动机的应用与展望［J］. 航空学报， 2025， 46（15）： 131427.
	YANG S M， WU J J， XIE C L， et al. Application issues of data-driven intelligent fault diagnosis technologies for liquid rocket engines［J］. Acta Aeronautica et Astronautica Sinica， 2025， 46（15）： 131427 （in Chinese）.
[2]	李斌，闫松，杨宝锋. 大推力液体火箭发动机结构中的力学问题［J］. 力学进展， 2021， 51（4）： 831-864.
	LI B， YAN S， YANG B F. Mechanical problems of the large thrust liquid rocket engine［J］. Advances in Mechanics， 2021， 51（4）： 831-864 （in Chinese）.
[3]	张凭，李斌，高玉闪，等. 重复使用火箭发动机推力室疲劳寿命研究进展［J］. 火箭推进， 2024， 50（1）： 12-27.
	ZHANG P， LI B， GAO Y S， et al. Research progress of fatigue life for the thrust chamber of reusable rocket engines［J］. Journal of Rocket Propulsion， 2024， 50（1）： 12-27 （in Chinese）.
[4]	张振臻，陈晖，高玉闪，等. 液体火箭发动机故障诊断技术综述［J］. 推进技术， 2022， 43（6）： 20-38.
	ZHANG Z Z， CHEN H， GAO Y S， et al. Review on fault diagnosis technology of liquid rocket engine［J］. Journal of Propulsion Technology， 2022， 43（6）： 20-38 （in Chinese）.
[5]	胡海峰. 液体火箭发动机智能故障诊断的研究现状［J］. 航天控制， 2023， 41（1）： 3-14.
	HU H F. Research status of fault diagnosis for liquid rocket engine［J］. Aerospace Control， 2023， 41（1）： 3-14 （in Chinese）.
[6]	武晓欣，贾洁羽，邢理想，等. 重复使用液体火箭发动机原位无损检测技术应用及展望［J］. 火箭推进， 2024， 50（1）： 46-56.
	WU X X， JIA J Y， XING L X， et al. Application and prospect of in-situ nondestructive testing of reusable liquid rocket engine［J］. Journal of Rocket Propulsion， 2024， 50（1）： 46-56 （in Chinese）.
[7]	WYETT L， REINERT J， MARAM J， et al. A plume spectrometry rocket engine condition monitoring experi-mentation method［C］∥ 25th Joint Propulsion Conference. Reston： AIAA， 1989.
[8]	TOSCANO A M， LATO M R， FONTANAROSA D， et al. Optical diagnostics for solid rocket plumes characterization： A review［J］. Energies， 2022， 15（4）： 1470.
[9]	李斌，李程，高玉闪，等. 重复使用运载火箭液体动力技术发展［J］. 火箭推进， 2024， 50（1）： 1-11， 171.
	LI B， LI C， GAO Y S， et al. Development of liquid propulsion technology for reusable launch vehicle［J］. Journal of Rocket Propulsion， 2024， 50（1）： 1-11， 171 （in Chinese）.
[10]	李斌，陈晖，马冬英，等. 500 tf级液氧煤油高压补燃发动机研制进展［J］. 火箭推进， 2022， 48（2）： 1-10.
	LI B， CHEN H， MA D Y， et al. Development of 500 tf class high pressure stage combustion LOX/kerosene rocket engine［J］. Journal of Rocket Propulsion， 2022， 48（2）： 1-10 （in Chinese）.
[11]	TEJWANI G D， BIRCHER F E， VAN DYKE D B， et al. Space shuttle main engine health monitoring with exhaust plume emission spectroscopy［J］. Journal of Spacecraft and Rockets， 1998， 35（3）： 387-394.
[12]	BIRCHER F， TEJWANI G， VA， et al. Engine diagnostic console-Recent development and test results and SSME data［C］∥ 31st Joint Propulsion Conference and Exhibit. Reston： AIAA， 1995.
[13]	TEJWANI G D， LANGFORD L A， VANDYKE D B， et al. Rocket engine plume diagnostics at stennis space center： SE-2003-05-00029［R］. Hancock： NASA Stennis Space Center， 2003.
[14]	CROSS G， BARKHOUDARIAN S. Advanced optical condition monitoring［C］∥ Aerospace Technology Confe-rence and Exposition. Warrendale： SAE International， 1991.
[15]	PATRICK M. An optical plume anomaly system to fly on DC-XA［C］∥ 33rd Joint Propulsion Conference and Exhibit. Reston： AIAA， 1997.
[16]	BENZING D， WHITAKER K， HOPKINS R， et al. Experimental verification of neural network-based SSME anomaly detection［C］∥ 33rd Joint Propulsion Conference and Exhibit. Reston： AIAA， 1997.
[17]	TEJWANI G， BIRCHER F， VAN DYKE D， et al. SSME health monitoring at SSC with exhaust plume emission spectroscopy［C］∥ 33rd Joint Propulsion Conference and Exhibit. Reston： AIAA， 1997.
[18]	余西龙，曾徽，林鑫，等. 可调谐二极管激光吸收光谱诊断技术：原理和应用［J］. 气体物理， 2016， 1（5）： 52-63.
	YU X L， ZENG H， LIN X， et al. Tunable diode laser absorption spectroscopy： Principle and application［J］. Physics of Gases， 2016， 1（5）： 52-63 （in Chinese）
[19]	谢小丽，嵇宏伟，向卓凡，等. 发动机尾焰原子光谱故障诊断技术研究［J］. 应用光学， 2026， 47（3）： 476-484.
	XIE X L， JI H W， XIANG Z F， et al. Research on fault diagnosis technology of engine exhaust plume atomic spectroscopy［J］. Journal of Applied Optics， 2026， 47（3）： 476-484.
[20]	DING C， ZHENG S R， ZHENG M M， et al. Diffusion-augmented cross-domain prototypical knowledge distilla-tion for few-shot learning in hyperspectral image classifi-cation［J］. IEEE Transactions on Geoscience and Remote Sensing， 2025， 63： 5518319.
[21]	韩明，李大海. 液体动力试验数字化转型技术进展与展望［J］. 火箭推进， 2024， 50（6）： 27-39.
	HAN M， LI D H. Development and prospect of digital transformation technology for liquid-propellant engine test［J］. Journal of Rocket Propulsion， 2024， 50（6）： 27-39 （in Chinese）.
[22]	闫松，李祎，郝耀龙. 液氧煤油发动机尾焰光谱测量及特征分析［C］∥中国力学大会-2025. 北京：中国力学学会， 2025： 179-186.
	YAN S， LI Y， HAO Y L. Spectral measurement and characteristic analysis of liquid oxygen/kerosene engine exhaust plume［C］∥ 2025 Chinese Congress of Theoretical and Applied Mechanics. Beijing： The Chinese Society of Theoretical and Applied Mechanics， 2025： 179-186.
[23]	RAINES N， BIRCHER F， CHENEVERT D. A subscale facility for liquid rocket propulsion diagnostics at Stennis Space Center［C］∥ 27th Joint Propulsion Conference. Reston： AIAA， 1991.
[24]	TEJWANI G D， VANDYKE D B， BIRCHER F E， et al. Emission spectra of selected SSME elements and materials： NASA-RP-1286［R］. Washington， D.C： NASA， 1992.
[25]	BIRCHER F E， TEJWANI G D， VALENTI E L， et al. Recent results in the development of the engine diagnostic console［C］∥ 1994 Conference on Advanced Earth-to-Orbit Propulsion Technology. Washington， D.C.： NASA， 1994： 190-199.
[26]	MADZSAR G. Determination of alloy content from plume spectral measurements［C］∥ 27th Joint Propulsion Conference. Reston： AIAA， 1991.
[27]	TEJWANI G， VAN DYKE D， BIRCHER F. Approach to SSME health monitoring. Ⅲ-Exhaust plume emission spectroscopy： Recent results and detailed analysis［C］∥ 29th Joint Propulsion Conference and Exhibit. Reston： AIAA， 1993.
[28]	DE GALAN L， SMITH R， WINEFORDNER J D. The electronic partition functions of atoms and ions between 1 500° K and 7 000° K［J］. Spectrochimica Acta Part B： Atomic Spectroscopy， 1968， 23（8）： 521-525.
[29]	PARSONS M L， SMITH B W， BENTLEY G E. Handbook of flame spectroscopy［M］. New York： Plenum Press， 1975： 300.
[30]	TEJWANI G D， THURMAN C C. Rocket engine plume spectral simulation and quantitative analysis［C］∥1994 Conference on Advanced Earth-to-Orbit Propulsion Technology. Washington， D.C.： NASA， 1994： 200-214.
[31]	ARNOLD J O， WHITING E E， LYLE G C. Line by line calculation of spectra from diatomic molecules and atoms assuming a Voigt line profile［J］. Journal of Quantitative Spectroscopy and Radiative Transfer， 1969， 9（6）： 775-798.
[32]	TEJWANI G， VAN DYKE D B， BIRCHER F， et al. SSME exhaust plume emission spectroscopy at SSC-Recent analytical developments and test results［C］∥ 31st Joint Propulsion Conference and Exhibit. Reston： AIAA， 1995.
[33]	POWERS W T， COOPER A E， WALLACE T L. Validation of UV-VIS atomic spectral model for qua-ntitative prediction of number density， temperature， and broadening parameter［C］∥ 22nd JANNAF Exhaust Plume Technology Subcommittee Meeting. Huntsville： JANNAF， 1995： 79-92.
[34]	WALLACE T， POWERS W， COOPER A. Simulation of UV atomic radiation for application in exhaust plume spectrometry［C］∥ 29th Joint Propulsion Conference and Exhibit. Reston： AIAA， 1993.
[35]	BENZING D A， WHITAKER K W. Approach to space shuttle main engine health monitoring using plume spectra［J］. Journal of Spacecraft and Rockets， 1998， 35（6）： 830-836.
[36]	WHITAKER K W. Analyzing rocket plume spectral data with neural networks for condition monitoring［C］∥RTO AVT Course on Intelligent Systems for Aeronautics. Neuilly-sur-Seine： NATO RTO， 2002.
[37]	WHITAKER K W， KRISHNAKUMAR K， RAVIKRISHNA R V， et al. Predicting species concen-trations in the SSME plume using neural networks［C］∥ 1994 Conference on Advanced Earth-to-Orbit Propulsion Technology. Washington， D.C.： NASA， 1994.
[38]	MADZSAR G， BICKFORD R， DUNCAN D. An overview of in-flight plume diagnostics for rocket engines［C］∥ 28th Joint Propulsion Conference and Exhibit. Reston： AIAA， 1992.
[39]	MADZSAR G C， BICKFORD R L， DUNCAN D B. Engine mounted optics for in-flight plume spectroscopy ［C］∥ 1994 Conference on Advanced Earth-to-Orbit Propulsion Technology. Washington， D.C.： NASA， 1994：141-151.
[40]	POWERS W T， COOPER A E， WALLACE T L， et al. Space shuttle main engine plume diagnostics： OPAD approach to vehicle health monitoring［J］. SAE Transactions， 1993， 102： 2021-2033.
[41]	SSME Engineering. SSME structural loads criteria： RSS-8561-24［R］. Canoga Park： Rockwell International， 1991.
[42]	MADZSAR G， BICKFORD R， DUNCAN D. Instrumentation for in-flight SSME rocket engine plume spectroscopy［C］∥ 30th Joint Propulsion Conference and Exhibit. Reston： AIAA， 1994.
[43]	FIORUCCI T， LAKIN II D， REYNOLDS T. Advanced engine health management applications of the SSME real-time vibration monitoring system［C］∥ 36th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit. Reston： AIAA， 2000.
[44]	MISHRA A K， MADHUMITHA M， DEVI R， et al. Comparative study on propellant characteristics for reusable launch vehicles［J］. International Journal of Universal Science and Engineering， 2021， 7（1）： 40-47.
[45]	GARDNER D G， TEJWANI G D， BIRCHER F E， et al. Stennis space center’s approach to liquid rocket engine health monitoring using exhaust plume diagnostics［C］∥ SAE Technical Paper Series. Warrendale： SAE International， 1991.
[46]	TEJWANI G， MCVAY G， LANGFORD L， et al. Hydrocarbon-fueled rocket engine plume diagnostics： Analytical developments & experimental results［C］∥ 42nd AIAA/ASME/SAE/ASEE Joint Propulsion Conference & Exhibit. Reston： AIAA， 2006.
[47]	OBERTACKE R， WINTRICH H， WINTRICH F， et al. A new sensor system for industrial combustion monitoring and control using UV emission spectroscopy and tomography［J］. Combustion Science and Technology， 1996， 121（1-6）： 133-151.
[48]	MATSUI Y， KAMIMOTO T， MATSUOKA S. A study on the time and space resolved measurement of flame temperature and soot concentration in a D. I. diesel engine by the two-color method［J］. SAE Technical Paper Series， 1979， 1： 790491.
[49]	CHEN Y Z， ZHENG Y W， LIANG D Z， et al. Fiber-tip Fabry-Perot cavity pressure sensor with UV-curable polymer film based on suspension curing method［J］. IEEE Sensors Journal， 2022， 22（7）： 6651-6660.
[50]	REN S F， CHEN S C， XU H Y， et al. Unsupervised representation learning-based spectrum reconstruction for demodulation of Fabry-Perot interferometer sensor［J］. IEEE Sensors Journal， 2023， 23（12）： 13810-13816.
[51]	WANG D， WU Y， SONG Y M， et al. High sensitivity fiber optic acceleration sensor based on Fabry-Perot interferometer［J］. Optical Fiber Technology， 2022， 72： 102989.
[52]	ZHU C， ZHENG H K， MA L M， et al. Advances in fiber-optic extrinsic Fabry-Perot interferometric physical and mechanical sensors： A review［J］. IEEE Sensors Journal， 2023， 23（7）： 6406-6426.
[53]	张林. 宽光谱干涉型法珀传感器信号的高速数据采集与处理［D］. 重庆：重庆大学， 2019：1-6.
	ZHANG L. High-speed data acquisition and processing of broadband spectral interferometric fiber Fabry-Perot sensor［D］. Chongqing： Chongqing University， 2019： 1-6 （in Chinese）.
[54]	BICKFORD R， MADZSAR G. Fabry-Perot inter-ferometer development for rocket engine plume spectro-scopy［C］∥ 26th Joint Propulsion Conference. Reston： AIAA， 1990.
[55]	JASSOWSKI D， MAKEL D， SAKABU R. Rocket engine condition monitoring and characterization with non-intrusive optical techniques［C］∥ 27th Joint Propulsion Conference. Reston： AIAA， 1991.
[56]	ZHAO N， LIN Q J， ZHANG F Z， et al. High-precision and long-range optical fiber Fabry-Perot interferometer for high temperature measurement［J］. Measurement Science and Technology， 2022， 33（11）： 115103.
[57]	XU Y F， QI H C， ZHAO X Y， et al. High-speed spectrum demodulation of fiber-optic Fabry-Perot sensor based on scanning laser［J］. Optics and Lasers in Engineering， 2024， 178： 108192.
[58]	杨帅. 高精度星载迈克尔逊干涉仪动镜及其稳定性支撑结构研究［D］. 西安：中国科学院大学（中国科学院西安光学精密机械研究所）， 2024： 2-7.
	YANG S. Research on the movable mirror and stability support structure of high precision spaceborne Michelson interferometer［D］. Xi’an： University of Chinese Academy of Sciences （Xi’an Institute of Optics and Precision Mechanics， Chinese Academy of Sciences）， 2024： 2-7 （in Chinese）.
[59]	刘国豪. 双干涉通道傅里叶变换成像光谱仪红外图谱重建及分析研究［D］. 长春：中国科学院大学（中国科学院长春光学精密机械与物理研究所）， 2024： 24-31.
	LIU G H. Reconstruction and analysis of infrared image and spectral of dual-interference channels imaging Fourier transform spectrometer［D］. Changchun： University of Chinese Academy of Sciences （Changchun Institute of Optics， Fine Mechanics and Physics， Chinese Academy of Sciences）， 2024： 24-31 （in Chinese）.
[60]	HELAND J， SCHÄFER K. Analysis of aircraft exhausts with Fourier-transform infrared emission spectroscopy［J］. Applied Optics， 1997， 36（21）： 4922-4931.
[61]	LINDQUIST D， HUDSON M， SHANKS R， et al. Infrared emission monitoring of rocket plumes［C］∥ 31st Joint Propulsion Conference and Exhibit. Reston： AIAA， 1995.
[62]	ROSS H R. Gas Emission Measurements from the RD 180 Rocket Engine［C］∥ 4th Conference on Aerospace Materials， Processes， and Environmental Technology. Orlando， 2001.
[63]	年福东，胡玉洁，陈富强，等. 激光诱导击穿光谱结合半监督序列学习的白芍重金属元素定量预测方法［J］. 中国激光， 2024， 51（23）： 2311003.
	NIAN F D， HU Y J， CHEN F Q， et al. Quantitative prediction of heavy metal elements in white peony root using laser-induced breakdown spectroscopy and semi-supervised sequential learning［J］. Chinese Journal of Lasers， 2024， 51（23）： 2311003 （in Chinese）.
[64]	MEHTA P， POPULWAR V， SHINDE N， et al. Laser induced breakdown spectroscopy： A promising analytical technique［J］. Indian Journal of Pharmaceutical Education and Research， 2025， 59（1）： 30-36.
[65]	LIN Q Y， DUAN Y X. Laser-induced breakdown spectroscopy： From experimental platform to field instrument［J］. Chinese Journal of Analytical Chemistry， 2017， 45（9）： 1405-1414.
[66]	LIMBECK A， BRUNNBAUER L， LOHNINGER H， et al. Methodology and applications of elemental mapping by laser induced breakdown spectroscopy［J］. Analytica Chimica Acta， 2021， 1147： 72-98.
[67]	曾庆栋，陈光辉，李文鑫，等. 基于粒子群-支持向量机算法的激光诱导击穿光谱钢铁快速检测与分类［J］. 光谱学与光谱分析， 2024， 44（6）： 1559-1565.
	ZENG Q D， CHEN G H， LI W X， et al. Classification of special steel based on LIBS combined with particle swarm optimization and support vector machine［J］. Spectroscopy and Spectral Analysis， 2024， 44（6）： 1559-1565 （in Chinese）.
[68]	ZHANG H， YUEH F Y， SINGH J P， et al. Laser-in-duced breakdown spectroscopy in a metal-seeded flame［C］∥ 35th Inter-society Energy Conversion Engineering Conference and Exhibit. Piscataway： IEEE， 2000： 595-600.
[69]	班德越. 基于免定标激光诱导击穿光谱的尾焰元素浓度测量研究［D］. 太原：中北大学， 2024： 4-7.
	BAN D Y. The measurement of elemental concentrations in the plume based on calibration-free laser-induced breakdown spectroscopy［D］. Taiyuan： North University of China， 2024： 4-7 （in Chinese）.
[70]	WANG Z， AFGAN M S， GU W， et al. Recent advances in laser-induced breakdown spectroscopy quantification： From fundamental understanding to data processing［J］. TrAC Trends in Analytical Chemistry， 2021， 143： 116385.
[71]	ZHAO Y C， YANG H R， HARILAL S S. Fiberoptic laser-induced breakdown spectroscopy system for in situ measurement in a hazardous environment［J］. Nuclear Technology， 2025， 211（5）： 1044-1055.
[72]	张振荣，方波浪，李国华，等. 时间分辨动态LIBS测量方法［J］. 光谱学与光谱分析， 2024， 44（4）： 952-955.
	ZHANG Z R， FANG B L， LI G H， et al. Time-resolved dynamic spectroscopy measurement for laser induced breakdown spectroscopy［J］. Spectroscopy and Spectral Analysis， 2024， 44（4）： 952-955 （in Chinese）.
[73]	LI X D， DUNKIN F， DEZERT J. Multi-source information fusion： Progress and future［J］. Chinese Journal of Aeronautics， 2024， 37（7）： 24-58.
[74]	ZHANG X W， WANG J， CHEN J L， et al. Retentive multimodal scale-variable anomaly detection framework with limited data groups for liquid rocket engine［J］. Measurement， 2022， 205： 112171.
[75]	SENGUPTA U， WAXENEGGER-WILFING G， MARTIN J， et al. Forecasting thermoacoustic instabilities in liquid propellant rocket engines using multimodal Bayesian deep learning［J］. International Journal of Spray and Combustion Dynamics， 2022， 14（3-4）： 218-228.
[76]	SHAO H D， LIN J， ZHANG L W， et al. A novel approach of multisensory fusion to collaborative fault diagnosis in maintenance［J］. Information Fusion， 2021， 74： 65-76.
[77]	YOON T， KIM S W， BYUN H， et al. Deep learning-based denoising for fast time-resolved flame emission spectroscopy in high-pressure combustion environment［J］. Combustion and Flame， 2023， 248： 112583.
[78]	ZHANG X G， HUA X H， ZHU J J， et al. Intelligent fault diagnosis of liquid rocket engine via interpretable LSTM with multisensory data［J］. Sensors， 2023， 23（12）： 5636.
[79]	ZHU M J， HUANG D， SHU K Q， et al. Determination of uranium in uranium ore by laser-induced breakdown spectroscopy （LIBS） and a two-dimensional convolutional neural network （CNN）［J］. Instrumentation Science & Technology， 2025： 1-15.
[80]	LI T F， ZHAO Z B， SUN C， et al. Multireceptive field graph convolutional networks for machine fault diagnosis［J］. IEEE Transactions on Industrial Electronics， 2021， 68（12）： 12739-12749.
[81]	HAO Z Q， LIU K， LIAN Q L， et al. Machine learning in laser-induced breakdown spectroscopy： A review［J］. Frontiers of Physics， 2024， 19（6）： 62501.
[82]	王天鑫. 新型片上法布里—珀罗滤光结构及其调制方法的研究［D］. 西安：中国科学院大学（中国科学院西安光学精密机械研究所）， 2024： 21-24.
	WANG T X. Research on novel on-chip Fabry-Perot filter structures and their modulation methods ［D］. Xi’an： University of Chinese Academy of Sciences （Xi’an Institute of Optics and Precision Mechanics， Chinese Academy of Sciences）， 2024： 21-24 （in Chinese）.
[83]	马英骁，李子园. 新型片上多光谱光电探测器的研究进展［J］. 红外与激光工程， 2025， 54（3）： 44-66.
	MA Y X， LI Z Y. Research progress of novel on-chip multispectral photodetectors［J］. Infrared and Laser Engineering， 2025， 54（3）： 44-66 （in Chinese）.
[84]	刘兆海，安昕辰，陶治，等. 基于MEMS-FPI片上光谱芯片的多组分痕量气体检测系统［J］. 光谱学与光谱分析， 2024， 44（2）： 359-366.
	LIU Z H， AN X C， TAO Z， et al. Multicomponent trace gas detecting and identifying system based on MEMS-FPI on-chip spectral device［J］. Spectroscopy and Spectral Analysis， 2024， 44（2）： 359-366 （in Chinese）.
[85]	XIA J N， XIA Y K， XIAO D， et al. LAS-on-edge： A real-time laser absorption spectroscopic water vapor sensor on edge computing platforms［J］. Sensors and Actuators B： Chemical， 2024， 418： 136258.
[86]	FOLTYNOWICZ A， MASŁOWSKI P， BAN T， et al. Optical frequency comb spectroscopy［J］. Faraday Discussions， 2011， 150： 23-31.
[87]	FORTIER T， BAUMANN E. 20 years of developments in optical frequency comb technology and applications［J］. Communications Physics， 2019， 2： 153.
[88]	李章顺，葛振杰，张慧萍，等. 高温超导体超快太赫兹光谱研究进展［J］. 光学学报（网络版）， 2025， 2（9）： 0913001.
	LI Z S， GE Z J， ZHANG H P， et al. Research progress on ultrafast terahertz spectroscopy of high-temperature superconductors［J］. Acta Optica Sinica （Online）， 2025， 2（9）： 0913001 （in Chinese）.
[89]	ZHANG W T， TURCHINOVICH D. Rigorous signal reconstruction in terahertz emission spectroscopy［J］. Optics Express， 2021， 29（15）： 24411-24421.
[90]	PLAZA A， BENEDIKTSSON J A， BOARDMAN J W， et al. Recent advances in techniques for hyperspectral image processing［J］. Remote Sensing of Environment， 2009， 113： S110-S122.
[91]	DENG C， HU X M， SUO J L， et al. Snapshot hyperspectral imaging via spectral basis multiplexing in Fourier domain［J］. Optics Express， 2018， 26（25）： 32509-32521.
[92]	CHEN Y P， LV J G， YUE W， et al. A snapshot infrared imaging Fourier transform spectrometer for dynamic target detection［J］. Remote Sensing， 2022， 14（7）： 1543.
[93]	CHEN Y P， LIANG J Q， ZHAO B， et al. Snapshot infrared Fourier transform imaging spectrometer for transient dynamic sensing［J］. Optics Express， 2025， 33（3）： 4024-4043.
[94]	DING K Y， ZHOU Q， CHEN M Y， et al. Deep learning empowered parallelized metasurface computed tomography snapshot spectral imaging［J］. Advanced Materials， 2025， 37（27）： 2419383.

元素	特征波长/nm
Al	308.22/309.27/394.40/396.15
Ca	422.67/443.50/445.48/445.58/534.95/558.88/559.45/585.75/610.27/612.22/616.22/616.95/643.91/644.98/646.26/647.17/649.38/649.97/671.77/714.81/720.22/732.62
Cr	357.87/359.35/360.53/396.37/425.44/427.48/428.97/434.45/435.18/520.45/520.60/520.84
Co	340.51/341.23/344.36/345.35/346.28/346.58/347.40/350.23/350.63/352.69/352.98/356.94/358.72/384.55/387.31/389.41/399.53
Cu	303.61/306.34/310.86/324.75/327.40/330.80/353.04/406.26/465.11/510.55/515.32/521.82/570.02/578.21/793.31/809.26
Fe	344.06/358.12/371.99/373.49/373.71/374.56/374.83/374.95/385.99/388.63/404.58/438.35
Mn	403.08/403.31/403.45/404.14
Mo	313.26/317.04/379.83/386.41/390.30/550.65
Ni	341.48/344.63/345.85/346.17/349.30/351.51/352.45/356.64/361.94
Na	330.23/330.30/449.42/449.77/568.82/589.00/589.59
Ti	319.20/319.99/334.19/335.46/337.14/363.55/364.27/365.35/374.11/375.29/394.87/395.63/ 395.82/398.18/398.98/399.86/430.11/430.59/453.32/453.47/498.17/499.11/499.95/500.72/501.42

合金	质量分数/%
合金	Ni	Fe	Cr	Mo	Ti	Al	Nb
GH4169	52.2	18.1	20.2	3.2	0.9	0.6	5.3
GH4061	57.2	14.0	17.1	3.8	0.6	1.0	4.8
GH202	66.0	2.0	18.2	4.5	2.6	1.3	/

故障描述	故障类型			材料牌号
故障描述	碰磨	掉块	烧蚀	材料牌号
涡轮盘烧蚀			√	GH4586
涡轮静子/壳体烧蚀			√	GH4061
低压壳体铸件掉块		√		S-08
诱导轮与低压壳体碰磨	√			诱导轮：GH4061 低压壳体：S-08

波长λ₀/nm	激发态能量E_n /cm^-1	统计权重g_n	爱因斯坦系数A_nm /（10⁸ s^-1）
425.43	23 499	9	0.315
427.48	23 386	7	0.307

评价指标	FPI	FTIR	LIBS
光谱范围	UV-VIS-NIR，瞬时透过带宽极窄	NIR-MIR（Mid-Infrared，中红外）宽谱覆盖（约 0.78~20.00 μm）	多在UV-VIS（取决于光谱仪），元素线丰富
光谱分辨	极高（10^-4 nm），适合线型参数反演	工程上典型1.0~4.0 cm⁻¹，优化后可达0.5~1.0 cm⁻¹	取决于光谱仪，通常优于0.1 nm
工程约束	对准直/对准、抗振、热漂移控制要求高	对可动镜位移精度与稳定性高度敏感	高能激光+精密光路+高速采集，抗振稳定与维护成本高；激光安全需评估
适用场景建议	线型/温度/流场参数反演、飞行小型化	气体组分定性与定量监测，多组分同步识别	元素识别与材料侵蚀相关金属元素，尤其低温或强背景工况
