分类信息辅助的自适应检测与跟踪方法

doi:10.7527/S1000-6893.2025.31553

Abstract

Abstract:

To address the challenges of target omission and data association errors in radar multi-target detection and tracking in cluttered environments， we respectfully propose a framework that integrates joint classification information， target detection， and target tracking. The classification information of targets and clutter based on distance-Doppler spectrum is utilized to assist detection and tracking. In the detection stage， we have designed an adaptive detection method to adjust the detection threshold based on the clutter background where the missed target is located， enabling re-detection. Furthermore， the classification information has the capability to filter the clutter measurements generated by re-detection. In the tracking phase， a neural enhancement message passing algorithm is used to unify the data association and measurement classification module. The Dempster-Shafer rule is used to fuse the probabilistic data association confidence and classification confidence， which may help to better allocate the confidence between different information sources， effectively solve the problem of information conflict， and improve the accuracy of data association. It is thought that this framework could be an effective way of linking classification information， target detection and target tracking. Experimental results combining radar measurement data and simulation data suggest that the proposed method could help avoid the problems of incomplete target tracking caused by target omission and the problem of erroneous shutdown between clutter and target. This method could improve the performance of radar target detection and tracking in cluttered environment.

Key words: target tracking, adaptive detection, neural network, classification information, message passing

CLC Number:

Enchun MA, Xianglong BAI, Quan PAN, Zengfu WANG. Classification information-assisted adaptive target detection and tracking method[J]. Acta Aeronautica et Astronautica Sinica, 2026, 47(3): 631553.

Figures/Tables 20

Table 1

Definition of factor nodes

因子节点	定义
$f X k$	$∏ i = 1 N k f x i, k$ ，其中 $f x i, k = p (x i, k \| x i, k - 1)$
$f S k$	$∏ i = 1 N k f s i, k$ ，其中 $f s i, k = p (s i, k \| s i, k - 1)$
$f Z k$	$∏ j = 1 M k ∏ i = 1 N k f z j, k i$ ，其中 $f z j, k i = p (z j, k \| x i, k) f F A (z j, k) a i, j, k$
$f E k$	$∏ i = 1 N k f E i, k$ ，其中 $f E i, k = p (E i, k (a ˜ i, k))$
$f I k$	$∏ j = 1 M k f I j, k$ ，其中 $f I j, k = p (I j, k (a ¯ j, k))$
$f A k$	$∏ i = 1 N k f a i, 0, k$ ，其中 $f a i, 0, k = P d (s i, k) ϑ 1 - a i, 0, k a i, 0, k = 0 1 - P d (s i, k) a i, 0, k a i, 0, k = 1$
$f Ω k$	$∏ j = 1 M k f Ω j, k$ ，其中 $f Ω j, k = p (a 0, j, k = 0 \| Ω j, k) a 0, j, k = 0 p (a 0, j, k = 1 \| Ω j, k) a 0, j, k = 1$

Table 1

Fig.1

Table 2

Table 3

Table 4

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Table 5

Fig.8

Fig.9

Fig.10

Fig.11

Fig.12

Table 6

Fig.13

Fig.14

References 38

[1]	GROSSI E， LOPS M， VENTURINO L. A novel dynamic programming algorithm for track-before-detect in radar systems［J］. IEEE Transactions on Signal Processing， 2013， 61（10）： 2608-2619.
[2]	邹鲲，廖桂生，李军，等. 非高斯杂波下知识辅助检测器敏感性分析［J］. 电子与信息学报， 2014， 36（1）： 181-186.
	ZOU K， LIAO G S， LI J， et al. Sensitivity analysis of knowledge aided detector in non-Gaussian clutter［J］. Journal of Electronics & Information Technology， 2014， 36（1）： 181-186 （in Chinese）.
[3]	卢术平，宋海洋，易伟，等. 基于雷达知识库的知识辅助恒虚警检测算法［J］. 现代雷达， 2017， 39（6）： 46-49， 58.
	LU S P， SONG H Y， YI W， et al. Knowledge-aided CFAR algorithm based on radar knowledge base［J］. Modern Radar， 2017， 39（6）： 46-49， 58 （in Chinese）.
[4]	刘红亮，周生华，刘宏伟，等. 一种航迹恒虚警的目标检测跟踪一体化算法［J］. 电子与信息学报， 2016， 38（5）： 1072-1078.
	LIU H L， ZHOU S H， LIU H W， et al. An integrated target detection and tracking algorithm with constant track false alarm rate［J］. Journal of Electronics & Information Technology， 2016， 38（5）： 1072-1078 （in Chinese）.
[5]	鲁瑞莲. 基于信息辅助的雷达检测跟踪一体化方法研究［D］. 西安：西安电子科技大学， 2018.
	LU R L. Study of information aided radar detection and tracking coprocessing［D］. Xi’an： Xidian University， 2018 （in Chinese）.
[6]	ZHAO H， SHAO X W， KATABIRA K， et al. Joint tracking and classification of moving objects at intersection using a single-row laser range scanner［C］∥2006 IEEE Intelligent Transportation Systems Conference. Piscataway： IEEE Press， 2006： 287-294.
[7]	BAE S H. Survey of amplitude-aided multi-target tracking methods［J］. IET Radar， Sonar & Navigation， 2019， 13（2）： 243-253.
[8]	ZHANG C， MU Y X， XIA Z H， et al. Feature extraction for moving targets based on the statistical characteristics of echo amplitude with the L-band fully polarimetric radar［J］. Remote Sensing， 2023， 15（1）： 80.
[9]	ZHONG J S， LUO Y T， ZHANG Y， et al. A novel approach to maneuvering target tracking based on random motion model using random Kalman filtering［C］∥International Conference on Signal Processing and Communication Security （ICSPCS 2022）. Washington， D.C.：SPIE， 2022： 22.
[10]	刘红亮，陈超，岳凯. 基于跟踪信息的多帧联合检测方法［J］. 系统工程与电子技术， 2021， 43（8）： 2124-2128.
	LIU H L， CHEN C， YUE K. Multi-frame joint detection method based on tracking information［J］. Systems Engineering and Electronics， 2021， 43（8）： 2124-2128 （in Chinese）.
[11]	GUAN Y S， WANG Y P. Joint detection and tracking scheme for target tracking in moving platform［C］∥2020 IEEE Radar Conference （RadarConf20）. Piscataway： IEEE Press， 2020： 1-4.
[12]	孙伟峰，李小彤，纪永刚，等. 基于检测-跟踪联动的紧凑型高频地波雷达弱目标自适应检测方法［J］. 电子与信息学报， 2023， 45（8）： 2955-2964.
	SUN W F， LI X T， JI Y G， et al. An adaptive weak target detection method using joint detection and tracking for compact high frequency surface ware radar［J］. Journal of Electronics & Information Technology， 2023， 45（8）： 2955-2964 （in Chinese）.
[13]	YANG W， FU Y W， LONG J Q， et al. Joint detection， tracking， and classification of multiple targets in clutter using the PHD filter［J］. IEEE Transactions on Aerospace and Electronic Systems， 2012， 48（4）： 3594-3609.
[14]	RICHARDS M A， SCHEER J A， HOLM W A. Principles of modern radar： Basic principles［M］. London： Institution of Engineering and Technology， 2010.
[15]	LI Y G， ZHANG G F， DOVIAK R J. Ground clutter detection using the statistical properties of signals received with a polarimetric radar［J］. IEEE Transactions on Signal Processing， 2014， 62（3）： 597-606.
[16]	SHI S N， LIANG X， SHUI P L， et al. Low-velocity small target detection with Doppler-guided retrospective filter in high-resolution radar at fast scan mode［J］. IEEE Transactions on Geoscience and Remote Sensing， 2019， 57（11）： 8937-8953.
[17]	SHUI P L， GUO Z X， SHI S N. Feature-compression-based detection of sea-surface small targets［J］. IEEE Access， 2019， 8： 8371-8385.
[18]	GAO C， YAN J K， PENG X J， et al. Signal structure information-based target detection with a fully convolutional network［J］. Information Sciences， 2021， 576： 345-354.
[19]	BAR-SHALOM Y， KIRUBARAJAN T， GOKBERK C. Tracking with classification-aided multiframe data association［J］. IEEE Transactions on Aerospace and Electronic Systems， 2005， 41（3）： 868-878.
[20]	BAI X L， WANG Z F， PAN Q， et al. Classification-aided robust multiple target tracking using neural enhanced message passing［J］. IEEE Transactions on Aerospace and Electronic Systems， 2025， 61（2）： 3882-3903.
[21]	WEN L W， DING J S， XU Z. Multiframe detection of sea-surface small target using deep convolutional neural network［J］. IEEE Transactions on Geoscience and Remote Sensing， 2021， 60： 5107116.
[22]	ZAECH J N， LINIGER A， DAI D X， et al. Learnable online graph representations for 3D multi-object tracking［J］. IEEE Robotics and Automation Letters， 2022， 7（2）： 5103-5110.
[23]	LUNA E， SANMIGUEL J C， MARTÍNEZ J M， et al. Graph neural networks for cross-camera data association［J］. IEEE Transactions on Circuits and Systems for Video Technology， 2023， 33（2）： 589-601.
[24]	WANG Z H， LI Z Y， LENG J X， et al. Multiple pedestrian tracking with graph attention map on urban road scene［J］. IEEE Transactions on Intelligent Transportation Systems， 2023， 24（8）： 8567-8579.
[25]	TEDESCHINI B C， BRAMBILLA M， BARBIERI L， et al. Cooperative lidar sensing for pedestrian detection： Data association based on message passing neural networks［J］. IEEE Transactions on Signal Processing， 2023， 71： 3028-3042.
[26]	JOHNSON M J， DUVENAUD D， WILTSCHKO A B， et al. Composing graphical models with neural networks for structured representations and fast inference［C］∥Proceedings of the 30th International Conference on Neural Information Processing Systems. New York： ACM， 2016： 2954-2962.
[27]	KUCK J， CHAKRABORTY S， TANG H， et al. Belief propagation neural networks［C］∥Proceedings of the 34th International Conference on Neural Information Processing Systems. New York： ACM， 2020： 667-678.
[28]	SATORRAS V G， AKATA Z， WELLING M. Combining generative and discriminative models for hybrid inference［C］∥Proceedings of the 33rd International Conference on Neural Information Processing Systems. New York： ACM， 2019： 13820-13830.
[29]	SATORRAS V G， WELLING M. Neural enhanced belief propagation on factor graphs［C］∥International Conference on Artificial Intelligence and Statistics.， 2020
[30]	SHAFER G. A Mathematical Theory of Evidence［M］. Princeton： Princeton University Press， 1976.
[31]	何友，修建娟，关欣，等. 雷达数据处理及应用［M］. 3版. 北京：电子工业出版社， 2013.
	HE Y， XIU J J， GUAN X. Radar data processing with applications［M］. 3rd ed. Beijing： Publishing House of Electronics Industry， 2013 （in Chinese）.
[32]	卜月华，王维凡，吕新忠. 图论及其应用［M］. 2版. 南京：东南大学出版社， 2015.
	BU Y H， WANG W F， LV X Z. Graph theory and its application［M］. 2nd ed. Nanjing： Southeast University Press， 2015 （in Chinese）.
[33]	梁建. 高频地波雷达目标二维CFAR检测及软件实现［D］. 青岛：中国海洋大学， 2014.
	LIANG J. Target CFAR detection method and software implementation with two-dimension data for HFSWR［D］. Qingdao： Ocean University of China， 2014 （in Chinese）.
[34]	OH S， RUSSELL S， SASTRY S. Markov chain Monte Carlo data association for multi-target tracking［J］. IEEE Transactions on Automatic Control， 2009， 54（3）： 481-497.
[35]	DE WIND H J， CILLIERS J E， HERSELMAN P L. DataWare： Sea clutter and small boat radar reflectivity databases［J］. IEEE Signal Processing Magazine， 2010， 27（2）： 145-148.
[36]	BAKKER R， CURRIE B. The McMaster IPIX radar sea clutter database［EB/OL］. （2023-11-01）［2024-11-01］. .
[37]	WENG X S， WANG J R， HELD D， et al. 3D multi-object tracking： A baseline and new evaluation metrics［C］∥2020 IEEE/RSJ International Conference on Intelligent Robots and Systems （IROS）. Piscataway： IEEE Press， 2020： 10359-10366.
[38]	SCHUHMACHER D， VO B T， VO B N. A consistent metric for performance evaluation of multi-object filters［J］. IEEE Transactions on Signal Processing， 2008， 56（8）： 3447-3457.

网络结构	作用
Conv.（8，（2，2），（0，1），（1，2））	特征提取
Batch normalization（8）， ReLU
MaxPooling（2，2）
Conv.（16，（2，2），（0，1），（1，2））
Batch normalization（8），ReLU
MaxPooling（2，2）
Conv.（32，（2，2），（0，1），（1，2））
Batch normalization（8），ReLU
MaxPooling（2，2）
Flatten layer
Linear（64，8），Sigmoid

网络结构	作用
Linear（9，8），ReLu	量测分类
Linear（8，4），ReLu
Linear（4，1），Sigmoid

雷达参数	CSIR数据集	IPIX数据集
中心频率/GHz	9	9.39
工作模式	驻留模式	驻留模式
脉冲重复频率/kHz	5	1

雷达参数	CIATDT方法	CFAR+NEMP方法
ATMR	0.975	0.768
AMOTA	0.864	0.767
RMSE-R	4.261	4.934
RMSE-V	0.046	0.044
MOSPA	5.512	5.704

雷达参数	CIATDT方法	CFAR+NEMP方法
ATMR	0.967	0.467
AMOTA	0.804	0.750
RMSE-R	4.561	5.034
RMSE-V	0.032	0.029
MOSPA	5.635	5.644
