飞行器非定常气动力稀疏识别建模方法

doi:10.7527/S1000-6893.2025.32764

Abstract

Abstract:

To enable efficient， high-fidelity construction of white-box reduced-order aerodynamic models， a frequency-domain unsteady aerodynamic modeling approach is proposed based on Sparse Identification of Nonlinear Dynamics （SINDy）. The proposed method uses simulation data of harmonic aircraft motions at representative amplitudes and frequencies， constructs a candidate function library guided by classical algebraic aerodynamic model architectures， and applies sparse regression to select optimal terms and identify parameters-thereby automatically yielding sparse， highly interpretable reduced-order aerodynamic models. Leveraging both classical algebraic model structures and Theodorsen’s unsteady aerodynamic theory， we formulate a globally sampled unified model （SINDyA） and a parameter-varying local model （SINDyB）. The approach is validated on two canonical problems-transonic pitch oscillations of the NACA64A010 airfoil and of the CHN-T1 aircraft-using lift and pitching-moment coefficients as modeling targets.Results indicate that the identified models require only a small number of dominant terms to capture the key nonlinear and hysteretic features of the unsteady aerodynamics； the SINDyB model， which performs local interpolation of coefficients， achieves higher prediction accuracy. Because the pitching-moment coefficient exhibits stronger nonlinearity， its prediction proves markedly more challenging than that of lift. The models predict aerodynamic responses accurately under small-amplitude excitations， while performance degrades for large-amplitude， high-frequency cases. These findings demonstrate the promise of symbolic machine-learning methods for constructing high-accuracy， interpretable unsteady aerodynamic models and highlight their potential for engineering application.

Key words: unsteady aerodynamics, machine learning, sparse identification, CFD, reduced-order model

CLC Number:

V212.11

Jinyang TONG, Jiaqing KOU, Weiwei ZHANG. Sparse identification modeling method for unsteady aerodynamics of aircraft[J]. Acta Aeronautica et Astronautica Sinica, 2026, 47(16): 132764.

Figures/Tables 24

Fig.1

Fig.2

Table 1

Geometric parameters

参数	数值
参考面积/ $m 2$	0.129 37
机翼半展长/ $m$	0.774 38
平均气动弦长/ $m$	0.193 7
力矩参考点/ $m$	（0.660 87，0，0）

Table 1

Table 2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

Table 3

Coefficients of each term in SINDyA model for NACA 64A010 airfoil

参数	系数
参数	$α$	$α k$	$α k 2$	$α k 3$	$α ˙ l g k$	$α ˙ k$	$α ˙ k 2$	$α ˙ k 3$	$α ˙ α ˙ l g k$	$α ˙ α ˙ k$	$α ˙ α ˙ k 2$	$α ˙ α ˙ k 3$
C_L	1.487	-1.327	1.714	-0.884	0.685	0.894	-0.577	-0.385	-1.162	2.246	0	-1.367
C_m	-1.577	1.519	-1.762	0.811	-0.772	-1.261	0	0.791	0.462	1.688	-1.849	0.53

Table 3

Fig.10

Fig.11

Table 4

Fig.12

Fig.13

Table 5

Coefficients of each term in SINDyA model for CHN-T1 standard model

参数	系数
参数	$α$	$α k$	$α k 2$	$α k 3$	$α ˙ l g k$	$α ˙ k$	$α ˙ k 2$	$α ˙ k 3$	$α α ˙ k 3$	$α ˙ α ˙ l g k$	$α ˙ α ˙ k$	$α ˙ α ˙ k 3$
C_L	1.244	-0.981	2.348	-1.556	-0.119	0	-0.697	0.653	-0.008	-0.094	-0.319	0.242
C_m	-0.995	1.753	-4.041	2.575	0.380	-2.706	6.169	-3.875	-0.815	0.811	0	0

Table 5

Table 6

Number of terms in SINDyB model

工况	项数
工况	C_L	C_m
$α m a x = 1 °, k = 0.102$	8	13
$α m a x = 1 °, k = 0.026$	7	7
$α m a x = 1 °, k = 0.015$	5	7
$α m a x = 4 °, k = 0.051$	11	10
$α m a x = 4 °, k = 0.02$ 0	15	9
$α m a x = 4 °, k = 0.013$	14	12
$α m a x = 8 °, k = 0.102$	12	13
$α m a x = 8 °, k = 0.026$	16	15
$α m a x = 8 °, k = 0.015$	15	14

Table 6

Fig.14

Table 7

Fig.15

Fig.16

Fig.17

References 52

[1]	KOU J Q， ZHANG W W. Multi-fidelity modeling framework for nonlinear unsteady aerodynamics of airfoils［J］. Applied Mathematical Modelling， 2019， 76： 832-855.
[2]	汪清，钱炜祺，丁娣. 飞机大迎角非定常气动力建模研究进展［J］. 航空学报， 2016， 37（8）： 2331-2347.
	WANG Q， QIAN W Q， DING D. A review of unsteady aerodynamic modeling of aircrafts at high angles of attack［J］. Acta Aeronautica et Astronautica Sinica， 2016， 37（8）： 2331-2347 （in Chinese）.
[3]	LUCIA D J， BERAN P S， SILVA W A. Reduced-order modeling： New approaches for computational physics［J］. Progress in Aerospace Sciences， 2004， 40（1-2）： 51-117.
[4]	GHOREYSHI M， JIRÁSEK A， CUMMINGS R M. Reduced order unsteady aerodynamic modeling for stability and control analysis using computational fluid dynamics［J］. Progress in Aerospace Sciences， 2014， 71： 167-217.
[5]	KOU J Q， ZHANG W W. Data-driven modeling for unsteady aerodynamics and aeroelasticity［J］. Progress in Aerospace Sciences， 2021， 125： 100725.
[6]	ABZUG M J， LARRABEE E E. Airplane stability and control［M］. Cambridge： Cambridge University Press， 2002.
[7]	GHOREYSHI M， CUMMINGS R M， RONCH A DA， et al. Transonic aerodynamic load modeling of X-31 aircraft pitching motions［J］. AIAA Journal， 2013， 51（10）： 2447-2464.
[8]	THEODORSEN T. General theory of aerodynamic instability and the mechanism of flutter： NACA-TR-496［R］. Washington， D.C.： NASA， 1977.
[9]	MCALISTER K W， LAMBERT O， PETOT D. Application of the ONERA model of dynamic stall： NASA-TP-2399［R］. Washington， D.C.： NASA， 1984.
[10]	张伟伟，寇家庆，刘溢浪. 智能赋能流体力学展望［J］. 航空学报， 2021， 42（4）： 20-65.
	ZHANG W W， KOU J Q， LIU Y L. Prospect of artificial intelligence empowered fluid mechanics［J］. Acta Aeronautica et Astronautica Sinica， 2021， 42（4）： 524689 （in Chinese）.
[11]	CHEN G， ZUO Y T， SUN J， et al. Support-vector-machine-based reduced-order model for limit cycle oscillation prediction of nonlinear aeroelastic system［J］. Mathematical Problems in Engineering， 2012， 2012： 152123.
[12]	HUANG R， HU H Y， ZHAO Y H. Nonlinear reduced-order modeling for multiple-input/multiple-output aerodynamic systems［J］. AIAA Journal， 2014， 52（6）： 1219-1231.
[13]	寇家庆，张伟伟，叶正寅. 基于分层思路的动态非线性气动力建模方法［J］. 航空学报， 2015， 36（12）： 3785-3797.
	KOU J Q， ZHANG W W， YE Z Y. Dynamic nonlinear aerodynamics modeling method based on layered model［J］. Acta Aeronautica et Astronautica Sinica， 2015， 36（12）： 3785-3797 （in Chinese）.
[14]	LI K， KOU J Q， ZHANG W W. Deep neural network for unsteady aerodynamic and aeroelastic modeling across multiple Mach numbers［J］. Nonlinear Dynamics， 2019， 96（3）： 2157-2177.
[15]	MURDOCH W J， SINGH C， KUMBIER K， et al. Interpretable machine learning： Ddefinitions， methods， and applications［EB/OL］. arXiv preprint： 1901.04592， 2019.
[16]	LI R Z， ZHANG Y F， CHEN H X. Physically interpretable feature learning of supercritical airfoils based on variational autoencoders［J］. AIAA Journal， 2022， 60（11）： 6168-6182.
[17]	LE CLAINCHE S， FERRER E， GIBSON S， et al. Improving aircraft performance using machine learning： A review［J］. Aerospace Science and Technology， 2023， 138： 108354.
[18]	ALI S， ABUHMED T， EL-SAPPAGH S， et al. Explainable artificial intelligence （XAI）： What we know and what is left to attain trustworthy artificial intelligence［J］. Information Fusion， 2023， 99： 101805.
[19]	HASSIJA V， CHAMOLA V， MAHAPATRA A， et al. Interpreting black-box models： A review on explainable artificial intelligence［J］. Cognitive Computation， 2024， 16（1）： 45-74.
[20]	YANG Z X， SHAN X L， YANG X I A， et al. Data-enabled discovery of specific and generalisable turbulence closures［J］. Journal of Fluid Mechanics， 2025， 1016： R1.
[21]	BRUNTON S L， PROCTOR J L， KUTZ J N. Discovering governing equations from data by sparse identification of nonlinear dynamical systems［J］. Proceedings of the National Academy of Sciences of the United States of America， 2016， 113（15）： 3932-3937.
[22]	RUDY S， ALLA A， BRUNTON S L， et al. Data-driven identification of parametric partial differential equations［J］. SIAM Journal on Applied Dynamical Systems， 2019， 18（2）： 643-660.
[23]	BRUNTON S L， KUTZ J N. Data-driven science and engineering［M］. 2nd ed. Cambridge： Cambridge University Press， 2022.
[24]	KAISER E， KUTZ J N， BRUNTON S L. Sparse identification of nonlinear dynamics for model predictive control in the low-data limit［J］. Proceedings of the Royal Society A： Mathematical， Physical and Engineering Sciences， 2018， 474（2219）： 20180335.
[25]	DAWSON S T M， BRUNTON S L. Improved approximations to Wagner function using sparse identification of nonlinear dynamics［J］. AIAA Journal， 2022， 60（3）： 1691-1707.
[26]	LELKES J， HORVÁTH D A， LENDVAI B， et al. Data-driven aerodynamic models for aeroelastic simulations［J］. Journal of Sound and Vibration， 2023， 564： 117847.
[27]	SUN C， TIAN T， ZHU X C， et al. Sparse identification of nonlinear unsteady aerodynamics of the oscillating airfoil［J］. Proceedings of the Institution of Mechanical Engineers， Part G： Journal of Aerospace Engineering， 2021， 235（7）： 809-824.
[28]	余永刚，周铸，黄江涛，等. 单通道客机气动标模CHN-T1设计［J］. 空气动力学学报， 2018， 36（3）： 505-513.
	YU Y G， ZHOU Z， HUANG J T， et al. Aerodynamic design of a standard model CHN-T1 for single-aisle passenger aircraft［J］. Acta Aerodynamica Sinica， 2018， 36（3）： 505-513 （in Chinese）.
[29]	LIMACHER E， MORTON C， WOOD D. Generalized derivation of the added-mass and circulatory forces for viscous flows［J］. Physical Review Fluids， 2018， 3： 014701.
[30]	GRAHAM M， LI J. Vortex shedding and induced forces in unsteady flow［J］. The Aeronautical Journal， 2024， 128（1328）： 2149-2190.
[31]	CASSEL K W， CONLISK A T. Unsteady separation in vortex-induced boundary layers［J］. Philosophical Transactions of the Royal Society A： Mathematical， Physical and Engineering Sciences， 2014， 372（2020）： 20130348.
[32]	XIA X， MOHSENI K. Unsteady aerodynamics and vortex-sheet formation of a two-dimensional airfoil［J］. Journal of Fluid Mechanics， 2017， 830： 439-478.
[33]	张子军，李怀璐，赵彤，等. 基于不确定性预测的气动力建模与主动采样［J］. 空气动力学学报， 2025， 43（1）： 12-21.
	ZHANG Z J， LI H L， ZHAO T， et al. Aerodynamic modeling and active sampling based on uncertainty prediction［J］. Acta Aerodynamica Sinica， 2025， 43（1）： 12-21 （in Chinese）.
[34]	PINTELON R， SCHOUKENS J. System identification： A frequency domain approach［M］. 2nd ed. Hoboken： Wiley-IEEE Press， 2012.
[35]	CORDES U， KAMPERS G， MEIßNER T， et al. Note on the limitations of the theodorsen and Sears functions［J］. Journal of Fluid Mechanics， 2017， 811： R1.
[36]	LIN G F， LAN C， BRANDON J， et al. A generalized dynamic aerodynamic coefficient model for flight dynamics applications［C］∥22nd Atmospheric Flight Mechanics Conference. Reston： AIAA， 1997.
[37]	DONOHO D L. Compressed sensing［J］. IEEE Transactions on Information Theory， 2006， 52（4）： 1289-1306.
[38]	CANDES E J， ROMBERG J， TAO T. Robust uncertainty principles： Exact signal reconstruction from highly incomplete frequency information［J］. IEEE Transactions on Information Theory， 2006， 52（2）： 489-509.
[39]	MANGAN N M， KUTZ J N， BRUNTON S L， et al. Model selection for dynamical systems via sparse regression and information criteria［J］. Proceedings of the Royal Society A： Mathematical， Physical and Engineering Sciences， 2017， 473（2204）： 20170009.
[40]	ZHANG L N， SCHAEFFER H. On the convergence of the SINDy algorithm［EB/OL］. arXiv preprint： 1805.06445， 2018.
[41]	CHIN S， LAN C E. Fourier functional analysis for unsteady aerodynamic modeling［J］. AIAA Journal， 1992， 30（9）： 2259-2266.
[42]	SKUJINS T， CESNIK C E S. Reduced-order modeling of unsteady aerodynamics across multiple Mach regimes［J］. Journal of Aircraft， 2014， 51（6）： 1681-1704.
[43]	王运涛，刘刚，陈作斌. 第一届航空CFD可信度研讨会总结［J］. 空气动力学学报， 2019， 37（2）： 246-261.
	WANG Y T， LIU G， CHEN Z B. Summary of the first aeronautical computational fluid dynamics credibility workshop［J］. Acta Aerodynamica Sinica， 2019， 37（2）： 246-261 （in Chinese）.
[44]	张耀冰，唐静，陈江涛，等. 基于非结构混合网格的CHN-T1标模气动特性预测［J］. 空气动力学学报， 2019， 37（2）： 262-271.
	ZHANG Y B， TANG J， CHEN J T， et al. Aerodynamic characteristics prediction of CHN-T1 standard model with unstructured grid［J］. Acta Aerodynamica Sinica， 2019， 37（2）： 262-271 （in Chinese）.
[45]	赵钟，何磊，何先耀. 风雷（PHengLEI）通用CFD软件设计［J］. 计算机工程与科学， 2020， 42（2）： 210-219.
	ZHAO Z， HE L， HE X Y. Design of general CFD software PHengLEI［J］. Computer Engineering and Science， 2020， 42（2）： 210-219 （in Chinese）.
[46]	赵钟，张来平，何磊，等. 适用于任意网格的大规模并行CFD计算框架PHengLEI［J］. 计算机学报， 2019， 42（11）： 2368-2383.
	ZHAO Z， ZHANG L P， HE L， et al. PHengLEI： A large scale parallel CFD framework for arbitrary grids［J］. Chinese Journal of Computers， 2019， 42（11）： 2368-2383 （in Chinese）.
[47]	李强，刘大伟，许新，等. CHN-T1标模2.4米风洞气动特性试验研究［J］. 空气动力学学报， 2019， 37（2）： 337-344.
	LI Q， LIU D W， XU X， et al. Experimental study of aerodynamic characterictics of CHN-T1 standard model in 2.4 m transonic wind tunnel［J］. Acta Aerodynamica Sinica， 2019， 37（2）： 337-344 （in Chinese）.
[48]	KOU J Q， ZHANG W W. Reduced-order modeling for nonlinear aeroelasticity with varying Mach numbers［J］. Journal of Aerospace Engineering， 2018， 31（6）： 04018105.
[49]	WANG X， KOU J Q， ZHANG W W. Unsteady aerodynamic prediction for iced airfoil based on multi-task learning［J］. Physics of Fluids， 2022， 34（8）： 087117.
[50]	GAO C Q， ZHANG W W， LIU Y L， et al. Numerical study on the correlation of transonic single-degree-of-freedom flutter and buffet［J］. Science China Physics， Mechanics & Astronomy， 2015， 58（8）： 84701.
[51]	寇家庆，张伟伟，高传强. 基于POD和DMD方法的跨声速抖振模态分析［J］. 航空学报， 2016， 37（9）： 2679-2689.
	KOU J Q， ZHANG W W， GAO C Q. Modal analysis of transonic buffet based on POD and DMD method［J］. Acta Aeronautica et Astronautica Sinica， 2016， 37（9）： 2679-2689 （in Chinese）.
[52]	KOU J Q， ZHANG W W. Layered reduced-order models for nonlinear aerodynamics and aeroelasticity［J］. Journal of Fluids and Structures， 2017， 68： 174-193.

网格	总网格量	第1层网格高度	y^＋
粗网格	2 318 948	1.44×10^-6	1.0
中等网格	5 952 147	1.00×10^-6	0.6
细网格	17 249 562	6.93×10^-7	0.4

模型	E_R/%		E_RMS/10^-3
模型	C_L	C_m	C_L	C_m
SINDyA	16.14	17.65	23.858	8.134
SINDyB	2.72	9.69	12.654	6.293

模型	C_L 的E_RMS	C_m 的E_RMS
SINDyA	0.108 9	0.284 7
SINDyB	0.047 7	0.221 0
